Demo Actieve luidsprekers

600W peak power Class-D amplifiers
300W RMS (200W LF + 100W HF)
8-inch subwoofer + 6 x 2.75-inch column array
Ultra-wide 120° x 30° coverage
Precision-DSP tuning and protection
3-channel built-in mixer with dual XLR/TRS combo inputs
2-band channel EQ with reverb to easily shape the sound of your sources
4 instant DSP application-specific speaker use modes for convenience and customization
Balanced XLR mix output for linking together with another speaker
Bluetooth streaming from phones, tablets, or laptops
Bluetooth TWS wireless stereo speaker linking
Wireless mixer and speaker control with Alto Pro App
Included column element shoulder bag

- Power output: 1000W
- German Engineering Class D ampli + switching power supply
- Freq. Response: 35 - 120 Hz
- Max. Output SPL: 133 dB
- Input SPL: -10 dBV
- Inputs: 2x XLR/1/4"
- Outputs: 2x XLR
- Woofer 18" x1
- DSP digital limiter
- 18 mm PLY cabinet
- Pole Socket: M20

- 2-way, bi-amp active vented design
- Power output: 700W
- German Engineering Class D ampli + switching power supply
- Freq. Response: 60 - 20 kHz
- Max. Output SPL: 126 dB
- Impedance: 4 Ohm
- Input SPL: -10 dBV
- Inputs: 1x XLR/1/4"
- Outputs: 1x XLR
- Woofer 10" x1
- 1,35" driver x1
- Directivity: 90° H x 60° V
- Crossover point: 1.9 kHz
- Power input: 220 / 240 Volt AC, 50 / 60 Hz
- LCD screen & multiple DSP
- 15 mm PLY cabinet
- Flypoints: M8
- Pole Socket: Φ35 mm

- 2-way active full range speaker
- Inputs: Bal XLR/TRS, 6.35, AUX, Bluetooth
- Outputs: Balanced XLR / TWS
- Power output: 250W (LF) + 50W (HF) RMS
- Bluetooth version: 5.0
- Power Input: 100/240 Volt AC, 50/60 Hz switchable
- Features: LF: German Engineering class D, HF: Class-AB
- DSP signal processing
- DSP parameters: Standard, Vocal boost, Live, Stage monitor
- EQ: Bass / Treble
- Freq. Range: 55 - 20 kHz
- Max. output SPL: 125dB (at max AMP output)
- Impedance: LF 4Ω / HF 8Ω
- 1.35" compression driver
- 12" woofer
- HPP moulded cabinet
- 35mm stand pole

AMPLIFIER:
- German Engineering Class D ampli + switching power supply
- Inputs: 2x XLR / TRS Line
- Outputs: 2x XLR Line
- Power output: 500 Watt RMS @ 8 Ohms / 1500 Watts Peak
- Main volume control
- Power input: 100/240 Volt AC, 50/60 Hz switchable
- Switchable phase (0/180°)
- LED indicator: Power, signal, clip
SPEAKER:
- Active vented subwoofer
- Freq. response: 35 - 150 Hz
- Max. output SPL: 133 dB
- Impedance: 8 Ohm
- 18" subwoofer, 3" VC 85 oZ
- Plywood cabin with black painted finish
- 1,5mm steel mesh
- 35mm stand pole
- Rubber cover on the edges

- 2-way, bi-amp active vented design
- Power output: 1000W
- German Engineering Class D ampli + switching power supply
- Freq. Response: 45 - 20 kHz
- Max. Output SPL: 129 dB
- Impedance: 4 Ohm
- Inputs: 1x XLR/1/4", 1x XLR
- Outputs: 1x XLR
- Woofer 15" x1
- 1,35" driver x1
- Directivity: 90° H x 60° V
- Crossover point: 1.6 kHz
- Power input: 220 / 240 Volt AC, 50 / 60 Hz
- LCD Screen & multiple DSP
- 15 mm PLY cabinet
- Flypoints: M10
- Pole Socket: Φ35 mm

- 2-way, bi-amp active vented design
- Power output: 1000W
- German Engineering Class D ampli + switching power supply
- Freq. Response: 50 - 20 kHz
- Max. Output SPL: 128 dB
- Impedance: 4 Ohm
- Input SPL: -10 dBV
- Inputs: 1x XLR/1/4", 1x XLR
- Outputs: 1x XLR
- Woofer 12" x1
- 1,35" driver x1
- Directivity: 90° H x 60° V
- Crossover point: 1.9 kHz
- Power input: 220 / 240 Volt AC, 50 / 60 Hz
- LCD screen & multiple DSP
- 15 mm PLY cabinet
- Flypoints: M10
- Pole Socket: Φ35 mm

• 2500W of Thunderous Bass
• High-efficiency Class D amplifier
• Transducer: 18-inch driver with 3-inch high-temperature voice coil
• Rugged, internally-braced front-ported MDF cabinet with integrated 36mm pole socket
• Mark-resistant splatter-spray finish always looks good, even with heavy use
• Electronic clip, thermal and transducer overdrive protection
• (2) XLR+1/4-inch combo inputs + (2) balanced XLR line outputs
• (2) XLR thru outputs for linking
• User-selectable EQ tunings (Off, Live, DJ)
• Phase Alignment selector switch (0°/90°/180°/270°)

- Output Power: 2500 W
- Low-Freq. Driver: 12.0” driver, 2.5” (63 mm) high-temp. voice coil. 1 x 800 W RMS @ 2 Ω
- High-Freq. Driver: 1.0” exit ceramic driver with 1.4” (35 mm) coil. 1 x 450 W @ 4 Ω
- Crossover Freq.: 2 kHz
- Max. SPL: 132 dB (peak), 129 dB (continuous) (dB-SPL @ 1 m)
- Freq. Response: 53 Hz – 20 kHz (+/-3 dB)
- Freq. Range: 44 Hz – 20 kHz (-10 dB)
- Horn Coverage: 90° horizontal x 60° vertical (nominal)
- Connectors: (2) XLR+1/4” (6.35 mm) TRS combo inputs (Balanced), (1) XLR output (Link), (1) IEC power cable input
- Input Impedance Line: 10 KΩ balanced, 20 KΩ unbalanced, Mic: 1.2K
- Line Gain/Volume Control Range: to 0 dB, +4 dBu nominal, +10 dBu for max output
- Mic/Inst. Gain/VolumeControl Range: to +50 dB
- USB Charging Port: 5V 2.1A
- Controls: Power switch, (2) gain control knobs (1 per input), (2) Mic/Line switches, Bluetooth volume control encoder, Pairing button, Stereo Link button, Sub Size button, Speaker Use button
- Indicators: (1) Input Channel Signal/Limit/Clip LED (Green = Ch1/2 Signal) (Yellow = Ch1/2 Limiter) (Red = Ch1/2 Output Clipped), (1) Bluetooth LED (Blue), (1) Link LED (Orange), (4) DSP Presets LED (Green), (3) HPF LED (Green)
- Power Connection: IEC
- Voltage: 100-120V, 50/60Hz; 220-240V, 50-60Hz
- Consumption: 1100W
- Fuse: 100-120V T15AL AC250V; 220-240V T6.3AL AC250V
- Protection: Electronic clip, thermal, and transducer overdrive protection
- Enclosure: Injected Molded Enclosure and Perforated Metal Grille
- Mounting/Installation: Standard 36 mm pole socket, flown application with integral M10 suspension points, or in a wedge monitor position
- Operating Temp.: -10°C to 45°C (14°F to 113°F)

- 15” ferrite woofer, 3” (76 mm) voice coil with long excursion
- Frequency Response (-6 dB): 45 Hz – 120 Hz
- Max SPL: 129 dB
- Class D 4000 W (peak) amplifier
- Boost / Extended LF / Normal DSP modes
- Inputs: Input: Left Mono (Combo) / Right (Combo)
- Output: Left Mono (XLR) / Right (XLR)
- Plywood cabinet enclosure
- 580 x 450 x 503mm dimensions
- 26.3 kg weight

-XPRS152 full-range speaker design
- 15” woofer
- 3” voice coil -
- 1” exit compression driver
- 1.75” voice coil for superb sound coverage across mid to large venues
- frequenxy response of 45Hz-20kHz
- max SPL of 133 dB
- class D 2000W

- 10” woofer, 2.5” voice coil
- 1” exit compression driver, 1.75” voice coil
- Frequency Response (-6 dB): 50 Hz – 20 kHz
- Max SPL: 129 dB
- Class D 2000 W (peak) amplifier
- Live / Music / Speech / Monitor DSP modes + 16 user customizable presets
- Inputs: MIC / LINE (Combo) / HI-Z / LINE (Combo) / 3.5 mm STEREO MINI
- Output: MIX (XLR)
- Plywood cabinet enclosure
- 299 x 520 x 310mm dimensions
- 15.5 kg weight

- max. SPL: 118 dB
- frequentierespons (+/- 10 dB): 50 Hz - 20 kHz
- vermogen (piek): 1200 W
- behuizing: PP/ABS
- Bluetooth: 5.0, TWS (stereo)
- inputs: 2x Mic/Line, 1x Aux/Bluetooth
- outputs: Mix Out, Bluetooth TWS
- Polar 8 subwoofer:
-- woofer: 1x 8 inch
-- afmetingen (BxDxH): 30.2 x 39 x 54 cm
-- gewicht: 13 kg
- Polar 8 Mid/High unit:
-- speakers: 6x 2.5 inch, neodymium
-- spreiding: 120° x 45°
-- afmetingen (BxDxH): 9.4 x 9.8 x 82 cm
-- gewicht: 3.2 kg
- Polar 8 Spacer:
-- afmetingen (BxDxH): 9.4 x 9.8 x 82 cm
-- gewicht: 2.3 kg
-- totale hoogte: 202.9 cm
-- totaal gewicht: 18.5 kg

-System power: 2,000 watts
-Frequency response: 38 Hz to 20 kHz
-Max SPL: 130 dB
-Premium subwoofer with a 12"
-Bluetooth
-Four-channel mixer: 3 x Mic/Line, 1 x Instrument, 1 x Aux
-32-bit DSP controller, integrated display
-3-band master EQ with semiparametric mids
-Multiple sound modes (Music, Voice, DJ and additional custom modes)
-Five programmable user presets
-Extra wide coverage angle (120°)
-With upgraded covers

IOS Stage Monitor 12
- Inputs: Bal XLR/TRS 6,35 mm
- Outputs: Balanced XLR
- Power Output: 350 RMS
- Power Input: 110/220 Volt, 60/50 Hz Switchable.
- Features: BI-AMP coaxial speaker LF: Class-D HF: Class-AB.
- Signal Processing: DSP
- DSP Parameter: Music/Flat/Low Cut/Stage/Vocal
- Frequency Range: 65 Hz - 20 kHz.
- Max output SPL: 123 dB.
- Sensitivity: 95 dB.
- Woofer: 12" ; 2,5" VC, 43 Oz.
- Driver: 1,35" Ferrite CD
- Cabinet: PLY painted cabinet.
- Fuse: T3.15AL / 250 Volt.
- Pole mount: 35 mm stand pole.
- Dimensions / Weight: 44,9 x 33,7 x 50,8 cm / 16 Kgs

Built-in 6-channel Digital Mixer
Advanced User Interface w/ touch panel and remote control
1.75" Compression Driver and 12" Woofer
Up to 130 dB Sound Pressure Level
2100W Class-D Bi-Amplification
Dual combo preamp with 48V Power and Mini-jack stereo line input
Bluetooth® stereo audio input, with dual speaker pairing option
True Resistive Waveguide, FiRPHASE, and Bass Motion Control

- Up to 130 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- 50-20000 Hz linear frequency response
- 1,75" Compression Driver
- 10" Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management

2200 W
135 dB max SPL
35 Hz - 120 Hz frequency response
18" Woofer, 4.0" v.c.
Multi-ply hardwood polyurea-coated
Selectable gain, X-over, cardioid mode and time delay
Stereo XLR input, Stereo XLR signal output

- 130 dB Max SPL
- 1400 WATT 2-way peak power
- Innovative DSP Processing
- 1" Compression Driver, 1.75" v.c.
- 15" Woofer
- 90°x60°, wide dispersion constant directivity horn
- FiRPHASE Technology

- Up to 131 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- 50-20000 Hz linear frequency response
- 1,75" Compression Driver
- 15" Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management

Frequentiebereik: 45 Hz ÷ 20000 Hz
Max SPL @ 1m: 135 dB
Horizontale dekkingshoek: 100°
Verticale dekkingshoek: 60°
TRANSDUCERS
Compressiedriver: 1 x 1.4'' neo, 4.0'' v.c.
Woofer: 15'' neo, 3.5'' v.c.
Crossover-frequenties: 650Hz
Bescherming: Thermisch, RMS
Limiter: Zachte Limiter
Bedieningselementen: Lineair, Boost, Stage, Volume
POWER SECTION Totaal vermogen:2100 W Piek
Hoge frequenties: 700 W piek
Lage frequenties: 1400 W piek
Koeling: Convectie
Aansluitingen: Powercon TRUE1 TOP IN/OUT
STANDAARD NALEVING
Veiligheidsagentschap: Volgzaam Ce
Materiaal behuizing/koffer: PP Composiet
Hardware: 1 x M10 Bovenkant, 1 x M10 elke kant
Handvatten: 1 Bovenkant, 1 elke kant
De Pool zet/kap op: Ja
Rooster: Staal
Kleur: Zwart

- Up to 131 dB Sound Pressure Level
- 2100W Class-D Bi-Amplification
- 45-20000 Hz linear frequency response
- 1.75" Compression Driver
- 15" Woofer
- FiRPHASE zero degrees phase technology
- Bass Motion Control woofer excursion management

134 dB Max SPL
Rotatable 100° x 70° TRW horn
12” neodymium woofer, 3.5” voice coil
3.0” Ti dome, neodymium compression driver
2 channel, 3200 W Class D Amplifier
DSP Processing with FiRPHASE and BMC
RDNet Networked Management
powerCON TRUE1 TOP mains connectors

2200 Watt Class-D Amplifier
135 dB MAX SPL
18” Woofer, bass reflex housing
Digital Crossover w/ Presets
Multi-ply hardwood polyurea-coated
LiveRemote App
Dual XLR/TRS combo Input + Link, Dual XLR Xover Out
Bass Motion Control excursion management
Powercon True1 Top Sealed AC Connector

- System type: Two way bass reflex
- MAX SPL: 130 dB
- Frequency Response (-10dB): 50Hz-20KHz
- HF: 1.35" (34mm) driver
- LF: 15" - 2.5" V.C (65mm)
- Coverage (H x V): 90° H x 60° V
- Crossover frequency: 1.8 kHz
- Amplifier class: D
- RMS Power: 600 W
- Peak Power: 1200 W
- Cooling: Fan
- Advanced Functions: FIR Filters
- DSP: 28/56 Bit
- Bluetooth: 5.0 (stereo)

EVOX 12 is the most powerful line-source in its class and offers a particularly profound and dynamic reproduction at high levels due to the built-in 1400W power amplifier. The top section has eight high performance neodymium 4"full-range transducers with a phase plug. As a result, the EVOX 12 has a significantly increased low-mid playback at a constant level with a wide dispersion for the highs.

Dilos System 1, Dilos Line array floor stackable configuration that includes 4 pcs 3 way active with DSP Dilos Plywood satelite and 2 pcs Dilos active plywood bandpass subwoofer with DSP.

- 8000 Watt Peak, 4000 Watt RMS
- 142 dB max SPL
- DOUBLE 19" RCF PRECISION Transducer
- I/O Panel Rain Cover Included
- RDNet Networked Control
- BMC, EQ, DLY, Cardioid
- Crossover Presets for RCF Speakers w/ FiRPHASE
- powerCON TRUE1 TOP AC Connector
- Detachable Front Cart (sold separately)

- Height: 533 mm / 20.98"
- Width: 1310 mm / 51.57"
- Depth: 785 mm / 30.91"
- Weight: 93 kg / 205.03 lbs

- Up to 137 dB Sound Pressure Level
- 4400W Class-D Bi-Amplification
- 30-120 Hz linear frequency response
- 2 x 18" High Power Woofers
- IP Rated Powercon TRUE1 TOP IN/OUT
- 8 Crossover Presets and 4 Cardioid Presets

134 dB max SPL
Rotatable 100° x 50° coverage
LF 2 x 10’’ neodymium woofer, 3.0” voice coil
HF 4.0” titanium dome, neodymium comp. driver
2 x Class-D amplifiers, 3200 Watt total power
DSP Processing with FiRPHASE and BMC
RDNet Networked Management
Advanced Rigging and powerCON TRUE1 TOP mains connectors

- Up to 138 dB Sound Pressure Level
- 2100W Class-D Amplifier
- 40-20000 Hz linear frequency response
- 1.75" Titanium Neodymium Compression Driver
- 8" Midrange, 2.5" v.c.
- 15" High Power Woofer
- Bass Motion Control and FiRPHASE processing
- M10 Rigging Points
- IP Rated Powercon TRUE1 TOP IN/OUT

Active Double Bass Reflex Subwoofer
B&C Custom 2x18"
5000W Class-D, 144dB Peak (Obs: wheels not includ.)

Active 3-way Point-Source Speaker
B&C Custom 2x12"
Coaxial Ring Radiator Driver
80°x45° Rotatable
1920W Class-D w/ 96kHz DSP
ethernet controlled via Software X-NET

18" Active Subwoofer

Product Type: Active Reflex Subwoofer
Frequency Response (-6dB): 36Hz - 160Hz
Maximum SPL Pgm/Peak (calculated): 130dB/133dB (Half-Space)
Subwoofer Driver: 1 x 18" (460mm), 4" (100mm) VC
Frequency / Type of X-Over: Adjustable on the Back Panel from 80Hz to 150Hz
Amplifier Technology: Class D Amplifier
Amplifier Power: 1000W/2000W
Control Type: X-Over Frequency Adjustment, Phase (0º or 180º), Input Level, Output Signal
Audio Signal Inputs: Line Input
Input Connectors: 1 x XLR / TRS combo
Audio Signal Outputs: Line Output (Input Link) or Post X-Over Line Output
Output Connectors: 1 x XLR
Operating Temperature Range: 0ºC - 40ºC
Cooling Type: Convection
Power Input: AC 100V - 240V 50Hz/60Hz
Mains Connector: Standard IEC socket
Power Consumption: 380W
Fittings: 1 x M20 and/or 35mm pole mount socket
Handles: 2 on each Side
Grille: Black Perforated Steel
Construction: Heavily Braced Multi-laminate Birch Plywood
Finish: Polyurea Coating
Dimensions (WxHxD): 560 x 545 x 780mm (22 x 21.5 x 30.7 in)
Net Weight: 47.5kg (104.7lb)
Shipping Weight: 54.5kg (120.2lb)
Accessories: Transportation Dolly | Individual Protective Cover

Product Type: Active Multi-Purpose Speaker
Frequency Response (-6dB): 46Hz - 20kHz
Low Frequency Extension (-10dB): 42Hz
Nominal Coverage (-6dB): 80º H x 50º V (User Rotatable)
Amplifier Technology: Class D Amplifier with DSP
Amplifier Power: RMS: 800W (550W + 250W) / Peak: 1400W
Mixer: 2 Channels
DSP Presets: Flat | HF Boost | Music | Wall | HPF 100Hz
Wireless Connection System: BT v4.0
Wireless Range: 10m (32.8ft)
Maximum SPL (calculated): 122dB / 128dB (Full-Space)
Low Frequency Driver: 12" Woofer | 2.5" Voice Coil
High Frequency Driver: 1" Titanium Driver | 1.7" Voice Coil
Audio Signal Inputs: BT | Microphone | Instrument | CD Player | AUX
Input Connectors: 2 x XLR / TRS combo | 1 x 3.5mm Stereo Jack | 1 x Stereo RCA
Audio Signal Outputs: Mixer Output
Output Connectors: 1 x XLR
Cooling Type: Convection
Power Input: AC 100V - 240V 50Hz/60Hz
Power Consumption: 550W (2.3A)
Fittings: 12 x M8 threaded inserts | 1 x 35mm pole mount socket
Handles: One on the Back
Grille: Black Perforated Steel
Construction: 15mm multi-laminate birch ply
Finish: Poliurea Coating
Dimensions (WxHxD): 356 x 578 x 398mm (14 x 20.8 x 15.7 in)
Net Weight: 20kg (44.1lb)
Shipping Weight: 23kg (50.7lb)
Accessories: U-Bracket (not included)

Product Type: Passive Two-way Vertical Array
Frequency Response (-6dB): 80Hz - 18.000Hz
Nominal Coverage (-6dB): 90º x 40º user rotatable
Program Power: 500W
Nominal Impedance: 4Ω
Sensitivity (1W, 1m): 95dB (Full-Space)
Maximum SPL (calculated): 121dB / 127dB (Full-Space)
Low Frequency Driver: 2 x 6.5" (170mm) / 1.5" (38mm) voice coil, custom speakers
High Frequency Driver: 1 x 1" (25mm) exit / 1.75" (44mm) voice coil, custom compression driver
Input Connectors: 2 x Neutrik NL4

Product Type: Active Reflex Subwoofer
Frequency Response (-6dB): 32Hz - X-over
Amplifier Technology: 2 channel switched mode class D with DSP
Subwoofer Amplifier Power: RMS: 1100W / Program: 1480W / Peak: 2960W
External Satellite Amplifier Power: RMS: 550W / Program: 740W / Peak: 1480W @ 4Ω
DSP Technology: Controlled Networkable DSP 24bit/48kHz
DSP Adjustable Parameters: 6 PEQ, Delay, HPF, LPF, Bass Enhancer, Level, Polarity, Mute
DSP Presets: 6 Factory and 2 User, selectable via software or rear panel switch
Control Type: Via RS485 and suplied software "SOUNDWARE"
Maximum SPL (calculated): 130.7dB / 136.7dB (Half-Space)
Subwoofer Driver: 1 x 15" (380mm) / 4" (100mm) VC, high excursion B&C custom speaker
Input Connectors: Signal: 2 x XLR ; Power: 2 x powerCON ; Output to external satellite: 1 x NL4
Power Input: 180V - 245VAC

Product Type: Flexible Active PA System - 1 x 15" + 2 x 8"
Frequency Response (-6dB): 40Hz - 19kHz
Nominal Coverage (-6dB): 50-100° H x 55º V (User Rotatable)
Amplifier Technology: Class D with DSP
Amplifier Power: RMS: 1000W | PGM: 2000W
DSP Technology: 24bit | 48kHz DSP
DSP Presets: Flat Indoor, Flat Outdoor, Music, DJ, Vocal
Control Type: Parameters Controlled on the Subwoofer Panel
FR Maximum SPL (calculated): 121dB
SW Maximum SPL (calculated): 127dB
Subwoofer Driver: 15" Woofer | 3" Voice Coil
Low Frequency Driver: 8" Woofer | 1.5" Voice Coil
High Frequency Driver: 1.4" Driver | 1.35" Voice Coil
Audio Signal Inputs: Mono / Stereo Analog Audio
Input Connectors: 2 x XLR / TRS Combo
Audio Signal Outputs: Mono / Stereo Analog Audio
Output Connectors: 2 x XLR
Speakers Output Connectors: 2 x NL4 (1+/1-)
Protections: Overload and Overcurrent
Operating Temperature Range: 0ºC - 45ºC (32ºF - 113ºF)
Cooling Type: Speed Controlled Fan
Power Supply: Switching Mode Power Supply (SMPS)
Power Input: AC 110V - 120V | AC 220V - 240V 50Hz/60Hz
Mains Connector: Standard IEC socket
Power Consumption: 280W (1/8 Max. Power)
Special Features: Subwoofer Phase (0º / 180º) | Input Type (Mono / Stereo) | Main Level Adjust. | Subwoofer Level Adjust.
Fittings: 35mm Pole Mount Socket
Handles: Subwoofer: One on Each Side | Satellite: One on Top
Grille: Powder Coated Steel Grille with Acoustical Foam
Construction: 12mm and 15mm Multi-Laminate Plywood
Finish: Poliurea Coating
Dimensions (WxHxD): Subwoofer: 440 x 655 x 583mm (17.3 x 25.8 x 23 in) | Satellite: 250 x 440 x 238mm (9.8 x 17.3 x 9.4 in)
Accessories: Speaker Cables and Subwoofer Wheels are included

TECHNICAL SPECIFICATIONS
Product Type: Active Reflex Subwoofer
Frequency Response (-6dB): 36Hz - X-over
Amplifier Technology: 2 channel switched mode class D with DSP
Amplifier Power: RMS: 2200W / Program: 2960W / Peak: 5920W
DSP Technology: Controlled Networkable DSP 24bit/48kHz
DSP Adjustable Parameters: 6 PEQ, delay, HPF, LPF, Bass Enhancer, Level, Polarity, Mute
DSP Presets: 6 Factory and 2 User, selectable via software or rear panel switch
Control Type: Via RS485 and suplied software "SOUNDWARE"
Maximum SPL (calculated): 136dB / 142dB (Half-Space)
Subwoofer Driver: 1 x 18" (450mm) / 4" (100mm) voice coil, long excursion, B&C custom speaker
Power Input: 180V - 245V
Mains Connector: Signal: 2 x XLR ; Power: 2 x powerCON;
Power Consumption: 770W
Fittings: 1 x 35mm Pole Mount Socket
Dimensions (WxHxD): 525 x 703 x 735 mm
Net Weight: 47.9kg

TECHNICAL SPECIFICATIONS
Product Type: Active Two-Way Speaker/Monitor
Frequency Response (-6dB): 54Hz - 18.000Hz
Nominal Coverage (-6dB): 90º x 60º user rotatable
Amplifier Technology: 2 channel switched mode class AB with DSP
LF Section Power
RMS: 400W / Program: 540W / Peak: 1080W
HF Section Power: RMS: 100W / Program: 135W / Peak: 270W
DSP Technology: Controlled Networkable DSP 24bit/48kHz
DSP Adjustable Parameters: 6 PEQ, delay, HPF, LPF, Bass Enhancer, Level, Polarity, Mute
DSP Presets: 6 Factory and 2 User, selectable via software or rear panel switch
Control Type: Via RS485 and suplied software "SOUNDWARE"
Maximum SPL (calculated): 126dB / 132dB (Full-Space)
Low Frequency Driver: 1 x 15" (380mm) / 3" (76mm) voice coil, custom speaker
High Frequency Driver: 1 x 1" (25mm) exit / 1.75" (44mm) voice coil, custom compression driver
Power Input: 90V - 245V
Mains Connector: Signal: 2 x XLR ; Power: 2 x powerCON
Power Consumption: 550W
Dimensions (WxHxD): 431 x 654 x 440 mm
Net Weight: 25.7kg
Shipping Weight: 28.5kg

Product Type: Active Two-Way Speaker/Monitor
Frequency Response (-6dB): 58Hz - 18.000Hz
Nominal Coverage (-6dB): 90º x 60º user rotatable
Amplifier Technology: 2 channel switched mode class AB with DSP
LF Section Power: RMS: 400W / Program: 540W / Peak: 1080W
HF Section Power: RMS: 100W / Program: 135W / Peak: 270W
DSP Technology: Controlled Networkable DSP 24bit/48kHz
DSP Adjustable Parameters: 6 PEQ, delay, HPF, LPF, Bass Enhancer, Level, Polarity, Mute
DSP Presets: 6 Factory and 2 User, selectable via software or rear panel switch
Control Type: Via RS485 and suplied software "SOUNDWARE"
Maximum SPL (calculated): 122dB / 128dB (Full-Space)
Low Frequency Driver: 1 x 12" (300mm) / 2.5" (65mm) voice coil, custom speaker
High Frequency Driver: 1 x 1" (25mm) exit / 1.75" (44mm) voice coil, custom compression driver
Power Input: 90V - 245V
Mains Connector: Signal: 2 x XLR ; Power: 2 x powerCON
Power Consumption: 550W
Dimensions (WxHxD): 356 x 554 x 410 mm
Net Weight: 20.6kg
Shipping Weight: 22.8kg

TECHNICAL SPECIFICATIONS
Product Type: Active Two-way Speaker
Frequency Response (-6dB): 60Hz - 18.000Hz
Nominal Coverage (-6dB): 90º x 60º user rotatable
Amplifier Technology: 2 Channel Switched Mode Class AB with DSP
LF Section Power
RMS: 400W / Program: 540W / Peak: 1080W
HF Section Power
RMS: 100W / Program: 135W / Peak: 270W
DSP Technology
Controlled Networkable DSP 24bit/48kHz
DSP Adjustable Parameters: 6 PEQ, Delay, HPF, LPF, Polarity, Bass Enhancer, Level, Mute
DSP Presets: 6 Factory and 2 User, Selectable via Software or Rear Panel Switch
Control Type: Via RS485 and Suplied Software "SOUNDWARE"
Maximum SPL (calculated): 118dB / 124dB (Full-Space)
Low Frequency Driver: 1 x 8" (210mm) / 2" (50.5mm) VC, custom speakers
High Frequency Driver: 1 x 1" (25mm) exit / 1.75" (44mm) voice coil, custom compression driver
Input Connectors: 2 x XLR; Power: 2 x powerCON
Power Input: 90V - 245VAC
Power Consumption: 550W
Dimensions (WxHxD): 254 x 415 x 301 mm
Net Weight: 11.8kg

* 1000 W RMS / 2000 W peak (LINEAR 5 MK II 118 Sub A) Class-D amp power
* Two lockable, balanced XLR/TRS Combo inputs, balanced XLR outputs for analogue loop-through to an additional speaker
* Remote-controlled high-performance DSP with integrated Remote and Cardioid presets
(Front, 1:1 vertical, 1:1 horizontal, Remote)
* DSP-Out: Balanced XLR output that transmits the processed signal from the speaker to a non-network-compatible speaker. The audio signal applied here can be extensively modified using the DSP CONTROL software
* Professional, lockable EtherCon connectors for connection to a Mac or PC to control the system via network; daisy chain connections possible
* M20 thread for mounting pole
* Enclosure made of birch multiplex (LINEAR 5 MK II 118 Sub A)

Can be used as a mid/high unit or as an onstage monitor
Packs the muscular bi-amped punch of a 1,200 W class D power amp
Beautifully balanced, high-definition audio
135 dB SPL that"s plenty of sound pressure for audiences of up to 500 (with the suitable L SUB 1500 A or L SUB 1800 A subwoofers)
No need for sophisticated audio skills: advanced DSP technology serves up top-notch sound every time

* 600 W RMS / 1200 W peak bi-amped Class-D power
amplifier
* Rotatable horns, coverage angle 80° x 60°
* Lockable, balanced XLR/TRS Combo input, balanced
XLR output for analogue looping to an additional
speaker
* Remote-controllable high-performance DSP with
integrated presets for the most common applications
* Professional, lockable EtherCon connector for
connection to a Mac or PC for network-based control of
the system
DSP Out: Balanced XLR output that transmits the
processed signal from the speaker to a non-networkcompatible speaker. The audio signal applied here can be extensively modifi ed using the DSP CONTROL
software
* HK Audio DuoTilt with 3° or 7° inclination
* Three reinforced M8 (AP - 8) mounting points, two
HK Audio butterfl y handles for the TB-NQ rigging
frame (LINEAR 5 MK II 115 XA, LINEAR 5 MK II 112 FA and
LINEAR 5 MK II 115 FA)
* Birch multiplex hybrid enclosure

Max. SPL @10% THD: 130 dB halfruimte (39 - 100 Hz gemiddeld).
Vermogen: RMS: 1.500W / Piek: 3000W.
Afstandsbedieningssoftware: DSP Control (Windows, macOS).

Powered subwoofer, 1200W, 1x 18? speaker, 132 dB max. SPL, rugged wood enclosure, ideal add-on to mid/high units from the LINEAR 3 family

Max. SPL @ 10 % THD: 133 dB.
Vermogen van de versterker: RMS - 600W / piek - 1,200W.
Laag-/midspeaker: 3x 8", 1,5" spreekspoel.
HF-driver: 1", 1,7" spreekspoel.
Hoorn directiviteit: 60° x +5/-25° MCT hoorn.
Afstandsbedieningssoftware: DSP CONTROL (Windows, macOS).

- Active 18? bass reflex subwoofer
- Now with a sturdy metal front grille with black acoustic foam backing
- Comes with the new HK Audio MultiGrips for significantly improved handling in any position
- 1,200-watt Class D power amplifier
- Includes stereo input on subwoofer with additional mid/high unit output (in addition to thru) for connecting active tops
- 2.1 system setup possible

- Active 12?/1? full-range, multifunctional speaker
- New flying option by installing the TB-45N/TB-45NQ tilt brackets
- Now with a sturdy metal front grille with black acoustic foam backing
- Comes with the new HK Audio MultiGrips for significantly improved handling in any position
- 1,200-watt Class D bi-amping
- Powerful DSP electronics with intuitive Plug ’n’ Play operation

Impactful sonic performance for larger, high-energy events
120° Wide, wave guide formed even coverage delivers crystal-clear audio everywhere
15” subwoofer with industry-leading laminar vent design unleashes powerful bass
Lightweight construction from advanced materials for unbeatable portability
Rapid deployment thanks to simple transport and setup gets the party started faster
QuickSmart link and Bluetooth Stereo for the ultimate connectivity

Incredible sonic performance for the ultimate sound at larger, high-energy events
120° Wide, wave guide formed even coverage delivers crystal-clear audio everywhere
Class-leading 18” subwoofer with industry-leading design unleashes the deepest bass
Lightweight construction from advanced materials for unbeatable portability
Rapid deployment thanks to simple transport and setup gets the party started faster
QuickSmart link and Bluetooth Stereo for the ultimate connectivity

- Krachtig en helder geluid tot 132 dB SPL.
- Efficiënte Klasse D-versterking met 3000 W piekvermogen
- QSC LEAF™-golfgeleider zorgt voor brede en gelijkmatige geluidsdekking (145° H x 35° V).
- Twee XLR-combo-ingangen (Mic/Line/Hi-Z en Mic/Line/+48 V) met aparte instellingen, ideaal voor kleine events met meerdere microfoons.
- Digitaal display voor instellingen zoals EQ, subwoofer, presets, Bluetooth®-configuratie
- Bluetooth met True Wireless Stereo (TWS) voor naadloze verbinding met linker- en rechterluidsprekers.
- Te gebruiken met of zonder kolompaal
- Verkrijgbaar in zwart en wit.
- Inclusief draagtas voor de topunit (KC12T) en kolompaal (KC-SP32).
- 6 jaar garantie bij registratie

-Power Rating: 1800 W
-LF Transducer: DVX3180A 457 mm
-Low Pass Frequency: Adjustable: 80 Hz, 100 Hz, 120 Hz, 150 Hz
-Connectors: (2) XLR/TRS Combo Jack and (2) XLR link Output
-Enclosure: 18 mm, 13-ply birch plywood with EVCoat
-Dimensions: 550 mm x 675 mm x 910 mm
-Net Weight: 51.8 kg

-Frequency Response: 55 Hz - 18 kHz
-Frequency Range: 48 Hz - 20 kHz
-Maximum SPL: 134 dB
-Coverage: 90" x 60"
-Power Rating: 1500 W
-LF Transducer: EVS-15M 381 mm (15 in)
-HF Transducer: DH-1M 1-inch titanium compression driver
-Crossover Frequency: 1.7 kHz
-Enclosure: 15 mm plywood with EVCoat
-Dimensions: 685 mm x 432 mm x 429 mm
-Net Weight: 24.4 kg

-Frequency Response: 48 Hz - 20 kHz
-Frequency Range: 40 Hz - 20 kHz
-Maximum SPL: 135 dB peak
-Coverage: 90° x 60°
-Power Rating: 2000 W
-LF Transducer: SMX2150 380 mm
-HF Transducer: DH3-B 1.25-in titanium compression driver
-Crossover Frequency: 1500 Hz
-Enclosure: 18 mm, 13-ply birch plywood with EVCoat
-Dimensions: 691 mm x 431 mm x 447 mm
-Net Weight: 27.7 kg

-Frequency Response: 85 Hz - 20 kHz
-Frequency Range: 65 Hz - 20 kHz
-Maximum SPL: 134 dB peak
-Coverage: 90° x 60°
-Power Rating: 2000 W
-LF Transducer: SMX2100 254 mm (10 in)
-HF Transducer: DH3-B 1.25-in titanium compression driver
-Crossover Frequency: 1700 Hz
-Dimensions: 526 mm x 330 mm x 365 mm
-Net Weight: 20.3 kg
-Enclosure: 18 mm, 13-ply birch plywood with EVCoat

Frequency response (-3 dB) (Hz) 1: 48 Hz – 18,000 Hz
Frequency range (-10 dB) (Hz) 1,2: 42 Hz – 20,000 Hz
Maximum sound pressure level at a distance of 1 m (dB) 3: 129 dB
Coverage angle HxV (°): 90° x 60°
Crossover frequency (kHz): 1.40 kHz
Power rating (W): 1000 W
Power consumption (V, Hz) 4: 100 - 240 V~, 50 - 60 Hz
LF transducer size (in): 15 in
HF transducer type: Compression driver
Material: Polypropylene
Dimensions (H x W x D) (mm): 697.6 mm x 422.8 mm x 383.1 mm
Weight (kg): 16.78 kg

Frequency response (-3 dB) (Hz) 1: 54 Hz – 18,500 Hz
Frequency range (-10 dB) (Hz) 1,2: 48 Hz – 20,000 Hz
Maximum sound pressure level at a distance of 1 m (dB) 3: 127 dB
Coverage angle HxV (°): 90° x 60°
Crossover frequency (kHz): 1.40 kHz
Power rating (W): 1000 W
Power consumption (V, Hz) 4: 100 - 240 V~, 50 - 60 Hz
LF transducer size (in): 12 in
HF transducer type: Compression driver
Material: Polypropylene
Dimensions (H x W x D) (mm): 621.1 mm x 356.2 mm x 356 mm
Weight (kg): 14.82 kg

EVIVA 18SP - 18” Portable Powered Subwoofer

- Signature Electro-Voice sound quality with selectable MUSIC/LIVE mode
- 1000 watt power rating with large, low-turbulence slot port provide high 132 dB maximum SPL
- Flexible line input connections and easy single-knob adjustment with dual-color input signal metering and peak detection
- Painted plywood enclosure with recessed input panel to protect controls and connectors in transit
- Universal mains voltage 100 V ~ 240 V auto-switching delivers reliable performance
- Ergonomic, lightweight design with durable metal side handles, antiskid bottom feet and M20 threaded pole mount plate

EVIVA 15P - Portable Powered Loudspeaker

- Signature Electro-Voice sound quality with selectable MUSIC/LIVE mode
- 1000 W power rating with high 126 dB maximum SPL
- Flexible mic/line input connections and easy single-knob adjustment with dual color input signal metering and peak detection
- Bluetooth® audio streaming with switchable mono/stereo mix output
- Universal mains voltage 100 V ~ 240 V auto-switching delivers reliable performance
- Ergonomic, lightweight design with side and top handles, bottom grab pocket and anti-skid bottom feet

EVIVA 12P 12" 2-way powered speaker

- Signature Electro-Voice sound quality with selectable MUSIC/LIVE mode
- 1000 W power rating with high 125 dB maximum SPL
- Flexible mic/line input connections and easy single-knob adjustment with dual color input signal metering and peak detection
- Bluetooth® audio streaming with switchable mono/stereo mix output
- Universal mains voltage 100 V ~ 240 V auto-switching delivers reliable performance
- Ergonomic, lightweight design with side and top handles, bottom grab pocket and anti-skid bottom feet

- Powerful yet versatile sub
- Integrated RDNet Hardware
- 1600 W RMS Amplifier
- Multiple configurations

Nettuno 50, het vlaggenschip van de Nettuno Serie. Dit systeem is ontworpen voor middelgrote tot grote zalen en beschikt over een actieve tweeweg top en twee actieve subwoofers, allemaal aangedreven door een geavanceerde versterker die een formidabel vermogen van 1600 W RMS levert.

De actieve tweeweg top is uitgerust met twee 12" woofers (2,5" V.C.) en een compressiedriver met een 1,4" hoornbelaste uitgang (3" V.C.) met een dekking van 100°x50° (HxV), wat zorgt voor een ongeëvenaard auditief spektakel.

- Effortless Setup
- Integrated RDNet Hardware
- 1600 W RMS Amplifier
- Multiple configurations

6x full-range 3.25" (1” V.C.) for each Top
2x 12" (3” V.C.) woofers
Effortless Setup
Integrated 8-Channel Mixer
1000 W RMS Amplifier
