Designed to mount small flat screens, the BT7510 is an ultra slim, fixed wall mount that is easy to install and mounts the screen just 15mm from the wall. Suitable for screens up to 20kg, the wall plate features 'OWLS' on wall levelling system to ensure a straight and smart installation and comes supplied with a security screw to help prevent unauthorized removal of the screen. The BT7510 is also compatible with B-Tech's range of poles and collars, increasing the number of different ways it can be mounted.
- Screen Size: up to 28” (71cm)
- Max. Weight: 20kg (44lbs)
- VESA Compatibility: 50 x 50, 75 x 75 & 100 x 100
- Dist from wall: 15mm (0.59”)
- Colour: Black.

Designed to mount small flat screens, the BT7511 features easy tilt adjustment of +17° / -10° and is suitable for screens up to 20kg, the wall plate features 'OWLS' on wall levelling system to ensure a straight and smart installation and comes supplied with security screws to help prevent unauthorized removal of the screen. The BT7511 is also compatible with B-Tech's range of poles and collars, increasing the number of different ways it can be mounted.
- Recommended screen size: up to 28” (71cm)
- Max load: 20kg (44lbs)
- VESA compatibility: up to 100 x 100
- Tilt: +17° / -10°
- Distance from wall: 55mm (2.16”)
- Colour: Black

Designed to mount small flat screens, this wall mount features both swivel and tilt functions. With the distance to wall at 93mm it allows easy positioning and a full 3600 rotation of the screen. Cover plates are included to hide fixings helping make this a neat and tidy mounting solution. BT7518 is also collar compatible for alternative mounting solutions, ideal for commercial applications as well as home installations.
Recommended screen size: up to 28" (71cm)
- Max load: 20kg (40lbs)
- VESA® compatibility: 75 x75 & 100 x 100
- Extension: 93mm (3.6")
- Tilt: +17/-10˚
- Swivel wall mounted: 50˚
- Swivel pole mounted: 180˚
- Screen rotation: 360˚
- Colour: Black

Designed to mount small flat screens, the BT7512 features a single swivel arm with easy tilt adjustment and a full 360° screen rotation for easy portrait or landscape mounting. The wall plate features 'OWLS' on wall levelling system to ensure a straight and smart installation. The BT7512 is also compatible with B-Tech's range of poles and collars, increasing the number of different ways it can be mounted, ideal for commercial applications as well as home installations. Security screws are are provided to help prevent unauthorized removal of the screen.
- Recommended screen size: up to 28” (71cm)
- Max load: 15kg (33lbs)
- VESA Compatibility: up to 100 x 100
- Tilt: +17° / -10°
- Swivel: 180°
- Rotation: 360°
- Distance from Wall: 75mm (3") to 280mm (11")
- Colours: Black

Designed to mount small flat screens, the BT7513 features a double articulated arm with easy tilt adjustment and a full 360° screen rotation for easy portrait or landscape mounting. The wall plate features 'OWLS' on wall levelling system to ensure a straight and smart installation. The BT7513 is also compatible with B-Tech's range of poles and collars, increasing the number of different ways it can be mounted, ideal for commercial applications as well as home installations. Security screws are are provided to help prevent unauthorized removal of the screen.
- Recommended screen size: up to 28” (71cm)
- Max load: 15kg (33lbs)
- VESA compatibility: up to 100 x 100
- Tilt: +17°, -10°
- Swivel at wall: 180°
- Screen rotation: 360°
- Distance from wall: 95mm (3.7") to 467mm (18.3")

Designed to mount medium sized flat screens, the BT7532 is an ultra-slim, fixed wall mount that is easy to install and mounts the screen just 15mm from the wall. Suitable for screens up to 40kg, the wall plate features 'OWLS' on wall levelling system to ensure a straight and smart installation and comes supplied with a security screw to help prevent unauthorized removal of the screen. The BT7532 is also compatible with B-Tech's range of poles and collars, increasing the number of different ways it can be mounted, ideal for commercial applications as well as home installations.
- Recommended screen size: up to 47” (119cm)
- Max load: 40kg (88lbs)
- VESA® compatibility: up to 200 x 200
- Distance from Wall: 15mm (0.6")
- Colour: Black

Designed for medium sized screens up to 40kg, the ultra-slim BT8200 mounts screens just 14mm from the wall and features post installation screen alignment, B-Tech's "On Wall Levelling System" and simple 'hook-on' installation to make screen mounting as quick and simple as possible. The BT8200 also features B-Tech's patented 'Torsion-Lock' security to help prevent un-authorised removal of the screen. All mounting hardware included.
- Recomended screen size: up to 47” (119cm)
- Max load: 40kg (88lbs)
- Unversal fixings: up to 240 x 200
- VESA® compatibility: up to 200 x 200
- Distance from wall: 14mm (0.5")
- Colour: Black

Designed to mount medium sized screens just 20mm from the wall, with its low-profile design the BTV500 is ideal for home installations. This mount features a simple ‘hook-on’ installation and post installation screen alignment to make screen mounting as quick and simple as possible. The BTV500 also features a security locking bar to help prevent un-authorised removal of the screen. All fixings and mounting hardware included.
- Recommended screen size: up to 47” (119cm)
- Max load: 40kg (88lbs)
- VESA® & non-VESA fixings: up to 225 x 200
- Distance from wall: 20mm (0.8")

Designed to mount medium sized screens, this wall mount is simple to install and features a tilt function that allows easy positioning of the screen. Suitable for screens with VESA patterns up to 200 x 200mm, this neat and tidy mounting solution is ideal for commercial applications as well as home installations. The BT7523 is also collar compatible for alternative mounting solutions. Security screws are are provided to help prevent unauthorized removal of the screen.
- Fits screens with VESA mounting patterns: 75 x 75mm, 100 x 100mm, 200 x 100mm and 200 x 200mm
- Easy tilt adjustment
- Mounts screen only 52mm from the wall
- Features ‘OWLS’ On Wall Levelling System
- Includes security locking screws and Allen key to prevent unauthorised removal of the screen
- Simple ‘hook-on’ installation with all mounting hardware included
- Compatible with B-Tech accessory collars

Designed to mount medium sized screens the BTV501 is ideal for home installations. With 5 fixed tilt poistions up to +15° available, this mount features a simple ‘hook-on’ installation and post installation screen alignment making screen mounting as quick and simple as possible. The BTV501 also features a security locking bar to help prevent un-authorised removal of the screen. All fixings and mounting hardware included.
- Recommended screen size: up to 47” (110cm)
- Max load: 40kg (88lbs)
- VESA® & non-VESA fixings: up to 225 x 200
Tilt: +15°
- Distance from wall: Flat: 44mm (1.7”) / Full tilt: 101mm (4”)

Designed to mount small to medium sized screens, this wall mount features swivel, tilt and full screen rotation which allows for quick and easy repositioning of the screen as required. Integrated cable management and spirit level help make this a neat and tidy mounting solution which is ideal for home installations as well as commercial applications.
- Recommended screen size: up to 47” (119cm)
- Max load: 25kg (55lbs)
- VESA® compatibility: up to 200 x 200
- Tilt: +/-15˚
- Swivel: 180˚
- Screen rotation: 360˚
- Distance from wall: 95mm (3.7”)

Designed to mount medium sized flat screens, the BT7514 features a single swivel arm with easy tilt adjustment. The wall plate features 'OWLS' on wall levelling system to ensure a straight and smart installation. The BT7514 is also compatible with B-Tech's range of poles and collars, increasing the number of different ways it can be mounted, ideal for commercial applications as well as home installations. Security screws are are provided to help prevent unauthorized removal of the screen.
- Recommended screen size: up to 47” (119cm)
- Max load: 25kg (55lbs)
- VESA Compatibility: up to 200 x 200
- Tilt: +/- 40°
- Swivel at wall: 180°
- Distance from wall: 95mm (3.7”) to 336mm (13.2”)
- Colour: Black

Designed to wall mount small to medium sized screens, this single arm wall mount features a rotating interface with tilt and swivel, allowing quick and easy repositioning of screens as required - the mount can display the screen folded flat against the wall or up to its maximum extension of 240mm. Cable management is included to help make a neat and tidy mounting solution which is ideal for home installations as well as commercial applications.
- Recommended screen size: up to 47” (119cm)
- Max load: 25kg (55lbs)
- VESA® compatibility: up to 200 x 200
- Tilt: +/-15°
- Swivel: 180°
- Screen rotation: 360°
- Distance from wall: 79mm (3”) - 240mm (9.4”)

Designed to mount medium sized flat screens, the BT7515 features a double articulated arm with easy tilt adjustment. The wall plate features 'OWLS' on wall levelling system to ensure a straight and smart installation. The BT7515 is also compatible with B-Tech's range of poles and collars, increasing the number of different ways it can be mounted, ideal for commercial applications as well as home installations. Security screws are are provided to help prevent unauthorized removal of the screen.
- Recommended screen size: up to 47” (119cm)
- Max load: 25kg (55lbs)
- VESA compatibility: up to 200 x 200
- Tilt: +/-40°
- Swivel at wall: 180°
- Distance from wall: 95mm (3.7”) to 525mm (20.6”)
- Colour: Black

Designed to wall mount small to medium sized screens, this double arm wall mount features a tilting interface and three swivel points, allowing quick and easy repositioning of screens as required - whether folded flat against the wall at a depth of 79mm or at maximum extension. Cable management is included to help make a neat and tidy mounting solution which is ideal for home installations as well as commercial applications.
- Recommended screen size: up to 47” (119cm)
- Max load: 25kg (55lbs)
- VESA® compatibility: up to 200 x 200
- Tilt: +/-15°
- Swivel: 180°
- Screen rotation: 360°
- Distance from wall: Min: 79mm (3”) - Max: 385mm (15”)

Designed for medium sized screens up to 35kg, the slim BT8421 mounts screens just 30mm from the wall and features post installation screen alignment, B-Tech's "On Wall Levelling System" and simple 'hook-on' installation to make screen mounting as quick and simple as possible. The BT8421 also features a security locking bar to help prevent un-authorised removal of the screen. All mounting hardware included.
- Recommended screen size: up to 55” (140cm)
- Max load: 35kg (77lbs)
- Universal fixings: up to 465mm (18.3") x 400mm (15.7")
- VESA® compatibility: up to 400 x 400
- Distance from wall: 30mm (1.2")

Designed to mount large sized screens just 20mm from the wall, with its low-profile design the BTV510 is ideal for home installations. Suitable for concrete, brick or stud walls up to 16”, this mount features a simple ‘hook-on’ installation and post installation screen alignment to make screen mounting as quick and simple as possible. The BTV510 also features a security locking bar to help prevent un-authorised removal of the screen. All fixings and mounting hardware included.
- Recommended screen size: up to 55” (140cm)
- Max load: 50kg (110lbs)
- VESA® & non-VESA fixings: up to 425 x 400
- Distance from wall: 20mm (0.8”)
- Colour: Black

Designed for medium and large sized screens, the BT8441 supports weights up to 80kg and features a low-profile design that mounts screens just 30mm from the wall. The universal interface accommodates mounting patterns up to 455 x 400mm and comes with adjustment screws which allow the screen to be levelled once mounted.
- Recomended screen size: up to 55" (140cm)
- Max load: 80kg* (176lbs)
- Fits universal patterns: up to 455 x 400mm
-Distance from wall: 30mm (1.2”)
- Colour: Black

Designed to mount medium to large sized screens, the BT8431 is a flat screen wall mount that features a unique ‘Torsion-Tilt’ mechanism which allows easy tilt adjustment of the screen up to +/-15°. Also suitable for pole mounting using B-Tech’s Accessory Collars, the BT8431 features levelling screws to adjust the screen level post installation as well as locking screws which help prevent unauthorised removal of the screen.
- Recommended screen size: 39” (99cm) - 55" (140cm)
- Max load: 50kg (110lbs)
- VESA® & non-VESA fixings: up to 468 x 400mm
- Tilt: +/-15°
- Distance from wall (flat): 81mm (3.2”)
- Distance from wall (full tilt): 148mm (5.8”)
- Colour: Black

Designed to mount large sized screens the BTV511 is ideal for home installations. With 5 fixed tilt poistions up to +15° available, this mount also features a simple ‘hook-on’ installation and post installation screen alignment making screen mounting as quick and simple as possible. The BTV511 includes a security locking bar to help prevent un-authorised removal of the screen. All fixings and mounting hardware included.
- Recommended screen size: Up to 55” (140cm)
- Max load: 50kg (110lbs)
- VESA® & non-VESA fixings: up to 425 x 400
- Tilt: +15°
- Distance from wall: Flat: 44mm (1.7”) / Full tilt: 153mm (6”)
- Colour: Black

Designed to mount large-sized screens, this ultra-slim wall mount with a double arm features a tilting interface and three swivel points, allowing quick and easy repositioning of the screen, whether folded flat to the wall or at maximum extension. A Cable management clip is included to help route cables along the double arm for a smart installation, ideal for home installations and commercial applications.
- Recommended screen size: up to 55" (140cm)
- Max load: 35kg (77lbs)
- VESA® & non-VESA fixings: up to 400 x 400mm
-Tilt: +10°/-2°
- Swivel: 180° (at wall) & 360° (at central pivot)
- Distance from wall: Min: 40mm (1.6”) - Max: 450mm (17.7”)

Designed for medium sized screens up to 70kg, the slim BT8422 mounts screens just 30mm from the wall and features post installation screen alignment, B-Tech's "On Wall Levelling System" and simple 'hook-on' installation to make screen mounting as quick and simple as possible. The BT8422 also features a security locking bar to help prevent un-authorised removal of the screen. All mounting hardware included.
- Recommended screen size: up to 80” (203cm)
- Max load: 70kg (154lbs)
- VESA® & non Vesa fixings: up to 840 x 500
- Distance from wall: 30mm (1.2")

Designed to mount large sized screens just 20mm from the wall, with its low-profile design the BTV520 is ideal for home installations. Suitable for concrete, brick or stud walls up to 32”, this mount features a simple ‘hook-on’ installation and post installation screen alignment to make screen mounting as quick and simple as possible. The BTV520 also features a security locking bar to help prevent un-authorised removal of the screen. All mounting hardware included.
- Recommended screen size: up to 65” (165cm)
- Max load: 70kg (154lbs)
- VESA® & non-VESA fixings: up to 825 x 500
- Distance from wall: 20mm (0.8”)
- Colour: Black

Designed for large sized screens, the BT8442 supports weights up to 80kg and features a low-profile design that mounts screens just 30mm from the wall. The universal interface accommodates mounting patterns up to 656 x 400mm and comes with adjustment screws which allow the screen to be levelled once mounted.
- Recommended screen size: up to 80" (203cm)
- Max load: 80kg* (176lbs)
- VESA® & non-VESA fixings: up to 656 x 400mm
- Distance from wall: 30mm (1.2")
- Colour: Black

Designed to mount large to extra-large sized screens, the BT8432 is a flat screen wall mount that features a unique ‘Torsion-Tilt’ mechanism which allows easy tilt adjustment of the screen up to +/-15°. Also suitable for pole mounting using B-Tech’s Accessory Collars, the BT8432 features levelling screws to adjust the screen level post installation as well as locking screws which help prevent unauthorised removal of the screen.
- Recommended screen size: up to 80" (203cm)
- Max load: 70kg* (154lbs)
- VESA® compatibility: up to 600 x 400
- Universal fixings: up to 677 x 400mm
- Tilt: +/-15°
- Distance from wall (flat): 81mm (3.2")
- Distance from wall (full tilt): 148mm (5.8")

Designed to mount extra-large sized screens the BTV521 is ideal for home installations. With 5 fixed tilt poistions up to +15° available, this mount features a simple ‘hook-on’ installation and post installation screen alignment making screen mounting as quick and simple as possible. The BTV521 also features a security locking bar to help prevent un-authorised removal of the screen. All fixings and mounting hardware included.
- Recommended screen size: Up to 65” (165cm)
- Max load: 70kg (154lbs)
- VESA® & non-VESA fixings: up to 825 x 500
- Tilt: +15°
- Distance from wall: Flat: 44mm (1.7”) / Full tilt: 183mm (7.2”)

Designed to mount medium to large sized screens, this universal double arm wall mount features an easy to tilt interface and three swivel points, for a quick, smooth repositioning of the screen - whether folded flat to the wall (at a depth of just 50mm) or at maximum extension. Cover plates and integrated cable management help hide all fixings for a neat and tidy mounting solution, ideal for both commercial and home installations.
- Recommended Screen Size: up to 65" (165cm)
- Max load: 35kg (77lbs)
- VESA® compatibility: up to 600 x 400
- Tilt: +14°/-3°
- Swivel: 180° at wall & interface, 360° at central pivot
- Distance from wall: Min: 50mm (2") - Max: 574mm (22.6")
- Colour: Black

Designed to mount medium to large sized screens, this ultra-slim twin cantilever arm wall mount features a tilting interface and three swivel points, allowing quick and easy repositioning of screens as required - whether folded flat to the wall at a depth of just 40mm or at maximum extension. Cover plates to hide fixings and integrated cable management help make this a neat and tidy mounting solution which is ideal for commercial applications as well as home installations.
- Recommended Screen Size: up to 75" (190cm)
- Max load (when tilt mechanism is tightened and set in a fixed position): 35kg (77lbs)
- Max load (when tool-less tilt function is required): 20kg (44lbs)
- VESA® compatibility: up to 600 x 400
- Tilt: +/-15°
- Swivel: 130°
- Extension: Min: 40mm (1.6") - Max: 469mm (18.5")
- Colour: Black or White

Designed to mount extra-large screens, the BT9901 is capable of supporting loads up to 100kg, making it ideal for mounting heavy duty touchscreens. The universal interface accommodates large mounting patterns up to 900mm x 600mm and features post installation screen alignment and simple 'hook-on' installation to make screen mounting quick and easy.
- Recommended screen size: 55” (140cm) - 100" (254cm)
- Max load: 100kg (220lbs)
- VESA® & non-VESA fixings: up to 900 x 600mm
- Distance from wall: 30mm (1.2")

Designed to mount the largest screens on the market, the heavy duty BT9903 is capable of supporting weights of 200kg when wall mounted. It is ideal for heavy touchscreens over 65" with the universal interface accommodating screens with mounting patterns up to 1000mm x 600mm. With keyhole fixings on the wall plate and a hook-on mounting system, the BT9903 is designed for an easy installation and features height adjustment screws which allow the screen to be levelled once mounted.
- Recommended screen size: 65” (165cm) up to 120" (305cm)
- Max load: 200kg* (440lbs)
- VESA® and non-VESA Fixings: up to 1000 x 600mm
-Distance from wall: 35mm (1.4")

Designed to mount the largest screens on the market, the heavy duty BT9910 is capable of supporting weights of 130kg when wall mounted. Ideal for screens over 65" the mount features a choice of 4 tilt positions from 0° up to 15° with the universal interface accommodating screens with mounting patterns up to 1000 x 600mm. With keyhole fixings on the wall plate and a hook-on mounting system, the BT9910 is designed for an easy installation and features height adjustment screws which allow the screen to be levelled once mounted.
- Recommended screen size: 65" (165cm) up to 100" (254cm)
- Max load: 130kg* (286lbs)
- VESA® and non-VESA fixings: up to 1000 x 600mm
- Tilt positions: 0°, 5°, 10° and 15°
- Distance from wall (when mounted flat): 82mm (3.2")
- Colour: Black

Designed to mount extra-large screens, this heavy-duty twin cantilever arm wall mount features an easy to tilt interface and three swivel points for quick, smooth repositioning of the screen - whether folded flat to the wall or at maximum extension. Featuring cover plates and integrated cable management for a tidy mounting solution, the BT8228 is ideal for both commercial and home installations.
- Recommended screen size: up to 120" (305cm)
- Max load: 125kg (275lbs)
- VESA® compatibility: 300 x 200 up to 800 x 600mm
- Tilt: -3°/+15°
- Swivel: 180°
- Distance from wall: Min: 90mm (3.5") - Max: 628mm (25")

The BT9920 is a dual-rail wall-mounted solution designed to mount extra-large displays over 72" and capable of supporting heavy loads up to 200kg, ideal for mounting sizeable digital signage displays or interactive screens with a simple hook-on installation. BT9920 features height adjustment screws that allow the screen to be levelled once mounted and integrated cable management, keeping the finished installation tidy.
- Recommended screen size: 72” (183cm) up to 120" (305cm)
- Max load: 200kg (440lbs)
- VESA® and non-VESA Fixings: up to 1600 x 800mm
- Distance from wall: 52mm (2")
- Colour (mounting rail): Black or Silver
- Colour (VESA arms): Black

The BT9921 is a dual rail, pop-out wall mount solution designed for extra large signage displays such as the LG 110UM5J-B. Capable of supporting heavy loads, the BT9921 is ideal for recess mounting and features a soft opening for full service access, micro-adjustment for screen alignment and integrated cable management to help keep the finished installation tidy. Safety screws also help to prevent unauthorised removal of the screen.
- Recommended screen size: 72” (183cm) up to 120" (305cm)
- Max load: 80kg (176lbs)
- VESA® and non-VESA Fixings: up to 1600 x 800mm
- Flat to wall depth: 115.3mm (4.5") (+/-7.5mm with micro-adjustment)
- Popped out depth: 268.3mm (10.6") (+/-7.5mm with micro-adjustment)
- Tool-less micro-adjustment: +/-7.5mm per corner
- Colour (mounting rail): Black or Silver
- Colour (VESA arms): Black

The BT7550 Rotational Flip Mount allows a mounted screen to be easily rotated from landscape to portrait orientation. The tool-less rotation adjustment allows the users to freely rotate the screen from 0° to 90° while mounted or locked at a preferred angle using the built in angle guide before mounting. Additional features include optional negative tilt of 4.5°, ideal for touchscreen displays such as the Samsung Flip®*. The BT7550 can be mounted directly to the wall or attached to other mounts in the B-Tech range for additional features such as pop-out mounting. Pole mounting using System 2 collars or directly to System X solutions can also be done easily.
- For screen sizes: 37" (94cm) - 65" (165cm)
- Max load: 70kg (154lbs)
- Angle adjustment range: 90°
- VESA® & non-VESA fixings: 200 x 200 up to 400 x 400
- Colour: Black

Designed for screens up to 65" in portrait orientation, the BT8322 is ideal for digital signage displays. The low-profile design mounts a screen just 36mm from the wall, can accommodate screens with VESA patterns up to 400 x 600 in portrait orientation, and can also mount screens in landscape orientation using 600 x 400 VESA patterns. BT8322 is supplied with adjustment screws that allow the screen to be levelled once mounted and safety screws feature to help prevent unauthorised screen removal.
- Recommended screen size: up to 65" (165cm)
- Max Load: 80kg (176lbs)
- Fits universal patterns: up to 400 x 600mm
- Distance from wall: 36mm*
- Colour: Black

The BT9923 is designed to mount XL ultrawide displays to a wall in portrait orientation. The mount is supplied with adaptor arms with vertical vesa fixings up to 1500mm; making it compatible with a wide selection of 21:9 ratio ultrawide displays. The low profile design mounts the display at a depth of 57.5mm (with adaptors) from the wall for a neat and tidy install whilst also allowing easy access to the connectors.
- Screen size: 105"-120" (267cm-305cm)
- Max load: 200kg (440lbs)
- Max VESA® fixings: 1500 x 600
- Dimensions (Without adaptors): W:705mm (27.7") x H:1256mm (49.5") x D:51.5mm (2.02")
- Colour: Black
